| Brand Name : | Hanfong,Winiversal |
| Certification : | CE,ROHS,ISO,TUV |
| Model Number : | SMP-40A |
| Delivery Time : | 7 work days |
| Payment Terms : | L/C, D/A, D/P, Western Union, MoneyGram, T/T |
| Supply Ability : | 100000 Piece/Pieces per Month |
| Price : | $73.44 |
Hanfong 2017 Auto Cooling 40A Illimité Solaire MPPT charge controller
MPPT 100/40
Untra-fast Maximum Power Point Tracking (MPPT)
Especially in case of a clouded sky, when light intensity is
changing continuously, an ultra fast MPPTcontroller will improve
energy harvest by up to 30%
compared to PWM charge controllers and by upto 10% compared to
slower MPPT controllers.
Advanced Maximum Power Point Detection in case of partial shading conditions
If partial shading occurs, two or more maximum power points may be
present on the power-voltage curve. Conventional MPPT's tend to
lock toalocal
MPP, which may not be the optimum MPP.The innovative fangpusun
algorithm will always maximize energy harvest by locking to the
optimum MPP.
Outstanding conversion efficiency
No cooling fan. Maximum efficiency exceeds 98%. Full output current up to 40°C (104°F).
Flexible charge algorithm
Fully programmable charge algorithm (see the software page on our website), and eight switch (see manual for details). preprogrammed algorithms, selectable with a rotagy
Extensive electronic protection
Over-temperature protection and power derating when temperature is
high.
PV short circuit and PV reverse polarity protection.
PV reverse current protection.
Internal temperature sensor
Compensates absorption and float charge voltage for temperature.
Real-time data display options
Apple and Android smartphones, tablets and other devices:
see the VE.Direct to Bluetooth low energy donegle.
ColorControl pannel
Certificates
Compliant with European Standards (CE)
RoHS compliant
SGS
ISO 9001
Made in China
Specifications
| Illimité Solaire charge controller | 10A | 15A | 20A | 30A | 40A | 50A | 60A | 70A | 80A |
| Range | 15V to 75V | 15V to 100V | 15V to 150V | ||||||
| Battery Vol. | 12/24 V Auto Select | 12/24/48 V Auto Select | |||||||
| Max. battery current | 10A | 15A | 20A | 30A | 40A | 50A | 60A | 70A | 80A |
| Max. PV power,12V 1a,b) | 150W | 175W | 300W | 450W | 600W | 750W | 900W | 1050W | 1200W |
| Max. PV power,24V 1a,b) | 300W | 350W | 600W | 900W | 1200W | 1500W | 1800W | 2100W | 2400W |
| Max. PV open circuit voltage | 75V | 100V | 150V | ||||||
| Peak efficiency | 98% | ||||||||
| Self consumption | Less than 10mA | ||||||||
| Charge voltage 'absorption' | Default setting 14.4V/28.8V | Default setting 24.4V/28.8V/57.6V | |||||||
| Charge voltage 'float' | Default setting 13.8V/27.6V | Default setting 13.8V/27.6V/55.2V | |||||||
| Charge algorithm | Multi-stage adaptive (eight preprogrammed algorithms) | ||||||||
| Temperature compensation | -16mV/ºC reap. -32mV/ºC | ||||||||
| Protection | Battery reverse polarity (fuse,not user accesssible) Output short circuit/Over temperature | ||||||||
| Operating temperature | -30 to + 60ºC (full rated output up to 40ºC) | ||||||||
| Humidity | 95%, non-condensing | ||||||||
| ENCLOSURE | |||||||||
| Colour | Blue | ||||||||
| PV terminals 2) | 4 mm² | 13 mm² | 35 mm²/ | ||||||
| Protection category | IP43(electronic components) | ||||||||
| IP22(connection area) | |||||||||
| Weight | 0.5kg | 1.25kg | 3kg | ||||||
Dimensions (h x w x d) mm | 100 x 113 x 40 | 130 x 186 x 70 | 200 x 250 x 95 | ||||||
| 1a)If more PV power is connected, the controller will limit input power to 720W resp.1440W. | |||||||||
| 1b)PV voltage must exceed Vbat + 5V for the controller to start. | |||||||||
| Thereafter minimum PV voltage is Vbat + 1V. | |||||||||
