We supply Solar Power Inverters, Solar controller for Home & business with high quality and competitive price. Hope to cooperate with you!
9 Years
| Ask Lasest Price | |
| Brand Name : | Hanfong |
| Model Number : | SMP-10 |
| Certification : | CE ISO ROSH |
| Price : | $27.8/pcs |
| Payment Terms : | T/T |
| Supply Ability : | 1000pcs/week |
| Delivery Time : | 15 days |
MPPT Solar Controller Introduction
SMP-10 series solar controller is an advanced MPPT controller than PWM controller to improve the charging efficiency over 30%~60%, which has the automatic identification system, PV wide input voltage range, can charge the battery discharge, the intelligent control mode. The maximum power point SMP series controller built-in sensitive tracking algorithm to quickly and accurately find the maximum in order to obtain the power point of the photovoltaic battery photovoltaic energy, more to improve the efficiency, reduce the cost of the system, is suitable for the amorphous silicon.
Features:
●Ultra fast Maximum Power Point Tracking (MPPT)
●Advanced Maximum Power Point Detection in case of partial shading conditions
●Extensive electronic protection
●Internal temperature sensor
●Adaptive three step charging
●Auto battery voltage recognition
●Flexible charge algorithms
●PV reverse polarity protection
●PV reverse current protection
Applications:
Solar system.
Specifications:
| Model | SMP 10A | SMP 15A | SMP 20A |
| Battery voltage | 12/24 V Auto Select | 12/24 V Auto Select | 12/24 V Auto Select |
| Maximum battery current | 10A | 15A | 20A |
| Maximum PV power,12V 1a,b) | 150W (MPPT range 15V to 75V) | 175W (MPPT range 15V to 75V) | 300W (MPPT range 15V to 75V) |
| Maximum PV power,24V 1a,b) | 300W (MPPT range 15V to 75V) | 350W (MPPT range 15V to 75V) | 600W (MPPT range 15V to 75V) |
| Maximum PV open circuit voltage | 75V | ||
| Peak efficiency | 98% | ||
| Self consumption | Less than 10mA | ||
| Charge voltage 'absorption' | Default setting 14.4V/28.8V | ||
