We supply Solar Power Inverters, Solar controller for Home & business with high quality and competitive price. Hope to cooperate with you!
9 Years
| Ask Lasest Price | |
| Brand Name : | Hanfong |
| Model Number : | ZA5000 |
| Certification : | ISO CE ROHS |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 1000pcs/week |
1) Featured with high reliability and low failure rate by using the
advanced Double-CPU single chip intellectual control technology.
2) Pure sine wave output.
3) Small, light and artistic, benefited from adopting the SMD
pastern technology.
4) Cooling fan is intellectual controlled, and its working status
is controlled by CPU, which mostly increased its service life and
helps to save the power consumption: improve work efficiency and
lower the working noise.
5) With complete protection:overload protection, internal
over-temperature protection, output short- circuit protection,
input under-voltage protection,input over-voltage protection,etc,
improving the reliability of the products greatly.
2) small sized emergency power supply system.
| Model | ZA5000 | |||||
| Input | DC voltage | 12V or 24V or 48V or 110V | ||||
| Voltage range | 10-16VDC or 20-33VDC or 40-63VDC or 90-135VDC | |||||
| No load current draw | < 2A | < 2A | ||||
| Efficiency | > 88% | |||||
| DC connection | Cables With Clips or Car Adaptor | |||||
| Output | AC voltage | 100/110/120VAC or 220/230/240 VAC | ||||
| Continuous power | 5000W | |||||
| Surge power | 10000W | |||||
| Waveform | Pure sine wave | |||||
| Frequency | 50Hz or 60Hz | |||||
| AC regulation | 3% | |||||
| Protection | Low voltage alarm | 10.5DC±0.5V or 21DC±1V or 42VDC±1V or 95VDC±3V | ||||
| Low voltage shut down | 10DC±0.5V or 20DC±1V or 40VDC±1V or 90VDC±3V | |||||
| Short circuit | Shut off output automatically | |||||
| Over load | Shut off output | |||||
| Over voltage shut down | 16V or 33V or 63V or 135V | |||||
| Over thermal | Shut off output automatically | |||||
| Environment | Working temperature | Between -10℃ and +50℃ | ||||
| Working humidity | 20%～90%RH | |||||
| Storage temperature | Between -30℃ and +70℃ | |||||
| Package | Machine size(cm) | 52*21.7*15.3 | ||||
| Packing size(cm) | 60.5*30*23 | |||||
| Net weight(kg) | 13.1 | |||||
| Gross weight(kg) | 15.5 | |||||
| Packing mode | Carton packaging | |||||
| Other | Start | Soft start | ||||
| Cooling ways | Intelligent cooling fan | |||||
|
|
