We supply Solar Power Inverters, Solar controller for Home & business with high quality and competitive price. Hope to cooperate with you!
9 Years
| Ask Lasest Price | |
| Brand Name : | Hanfong |
| Model Number : | HFS-500P |
| Certification : | ISO CE ROHS |
| Price : | $280 / PCS |
| Payment Terms : | T/T, D/P, L/C, Western Union, MoneyGram |
| Supply Ability : | 2000PCS / WEEK |
| Delivery Time : | 7DAYS |
300W Solar Energy System with Pure Sine Wave Sine Inverter Solar Panels100W Recommend Battery65Ah
The Specification of 300w solar power system
| Model | Parts | Data | Packing |
| HFS-300P | Pure Sine Wave Sine Inverter | Output Power:300W(600WPeak Power) | Products Size:500*300*400 Packing Size:640*437*538 NW:20KG GW:24.58KG |
| AC Voltage:AC220V±5V | |||
| Conversion efficiency:85% | |||
| Output Wave:Pure Sine Wave | |||
| Hz:50Hz(±5Hz) | |||
| PWM Solar Charger Controller | Rated voltage(v):12V | ||
| Rated Current(A):20A | |||
| Maximum charging current20A | |||
| Speaker | Input voltageAC220V DC12-24V | ||
| Maximum output power:100W | |||
| Sensitivity:90DB | |||
| Frequency response range:40Hz-5KHz | |||
| Recommend the solar panels | 100WPoly solar panel*2 | ||
| Recommend battery | 65A Lead-acid battery*1 |
System operating instructions
1)When using a direct current, turn on dc output switch first, then the inside controller starts to work. All of the dc voltage is outputted by the controller output, USB 5 v dc and dc 12 v and power amplifier can work normally.
2)When need cell phone charge, insert the multifunctional mobile phone charging line to USB dc 5 v output, choosing a suitable charging connector, can be charged after connection.
3)Dc 12 v output has a single 4-way output, when need 12 v lights, insert the 12 v lights to LED lamp output jack, open the corresponding output switch, then LED lamp can be used. Meanwhile, the corresponding LED indicator light will light up, you can also use the A B C D four buttons on the remote control to control the corresponding 12 v lights.
4)When need to use the power amplifier, switch on the power amplifier, power amplifier indicator light will light up, insert U disk or connect a bluetooth and other audio signal input, can play music.
5)If you don't use dc, dc output switch can be closed.
|
|
